2007 Chinese brand 700mm 4hi stainless steel CRM
stock No.: 220, it is written on April 5, 2022- product description
- Technical Parameters
this is 4 hi reverse cold rolling mill to make stainless steel200, 304,430 series.
motro pressing down.
coil width max 700mm.
max coil OD: 1800mm
coil ID 508mm. or 610mm
max coil weight: 12 t
max speed: 150m/min
max rolling force: 8000kn
housing size: 420x480mm, 35# casting steel
incoming thickness: 2--4mm
product thickness: 0.3--0.8mm
2 solid coiler.
coiler DC motor: 560kw X2 400/1000 rpm
max coling tension: 160 kn
rolling mill DC motor:900kw 380/1000rpm
driven by back up rolls.
DC driver Ansaldo
working roll width: 800mm, diameter: 190mm
back up roll width: 750mm, diameter:750mm
spare working rolls: 35 PCS
spare back up rolls: 6 PCS
hydraulic system, electric system are complete.
motor pressing down, machine is on dismantled.
one set of radiation thickness gauge (but we cannot supply radiation source because this is dangerous parts)
machine total weight: 180--190t
machine was made in Wuxi in 2007.
