used cold rolling mill
Your current location:首页 > Products > used cold rolling mill > used 14hi cold rolling mill stainless steel
used 14hi cold rolling mill stainless steel
Stock Number: 508, it is written on April 2, 2023
- product description
- Technical Parameters
it is 14hi.
material: SUS200, 300, 400serial stainless steel
input: hot rolled 1.0-3.0 × 350-650mm hot rolled 0.5-1.2 ×350-650mm(soft condition)
coil ID: 508mm
coil OD: 750-1600mm
max. coil weight: 8000kg
output size: 0.08-1.5×350-650mm
line speed: 0-120m/min
recoiling tension: 3KN-30KN
uncoiler motor: 67KW
Expansion and contraction reel OD: 480-540mm
recoiling speed: 0-120m/min
hydraulic oil tank: 1m3(ss)
back up roll: OD520×720mm
backing roll: OD225×720mm
middle roll: OD115×730mm
1st layer back up roll: OD85×820mm
work roll: OD48×750mm
rolling force: 3000KN
rolling speed: 0-180-300m/min
hydraulic AGC, pressing speed: 0-3mm/s
main drive motor: 660V, 1360A, 900KW, 600/1000 r/min
back up roll material: 9Cr2Mo, roll surface hardness: Hs79-84
work roll material: alloy steel, Heat treatment hardness: HRC35-40
recoiling tension: high speed 20KN-200KN, low speed 12KN-120KN
recoiler motor: 660V, 1310A, 800/700KW
PLC: Siemens S7-300
If you want to quote or further information on this product, please fill out the form below.
