used cold rolling mill

Your current location:首页 > Products > used cold rolling mill > 1974 LOEWY ROBERTSON 1600mm 4hi one stand one direction cold rolling mill aluminum foil

1974 LOEWY ROBERTSON 1600mm 4hi one stand one direction cold rolling mill aluminum foil

stock No.: 333, it is written on June 1, 2022. B-2
  • product description
  • Technical Parameters

machine is made in 1974, by LOEWY ROBERTSON

material: aluminum

coil width: max.1600mm

input thickness: 0.50mm

output thickness: 0.02-0.006mm

uncoiler motor: 70KW×2 DC

main motor: 70KW×2 DC

recoiler motor: 522KW×2 DC

line speed: max. 800m/min

work roll size: OD310×1950mm

back up roll size: OD875×1850mm

total weight: approximate 500 ton

exclude electric control system

above specifications are only reference, If there is any discrepancy,

please follow all specifications at used machine site

If you want to quote or further information on this product, please fill out the form below.
