material                                 Q195、Q235、08Al、SPHC、SPHD

material width ×thickness       800～1270×1.5～3.5mm product width×thickness   800～1270×0.20～1.5mm coil weight(Max.)                                                          25.0t

rolling pressure           20000KN

threading speed          ～0.5m/s

rolling speed(max.)      900m/min

working rolls                    Φ420/380×1450mm

middle rolls                       Φ480/430×1400mm

back up rolls                    Φ1350/1280×1350mm

middle roll moving distance      330mm

open mouth：                 25mm

max torque：               150KN·M

working roll bending force：  +400KN

middle roll bending force：    +400KN

-300KN

main transmission motor     2×2000KW

max recoiling tension       150KN

recoiler motor           2×1250KW

uncoiling speed          6m/s

uncoiling tension        75KN

uncoiler motor            453KW

pressing type               hydraulic pressing

product accuracy        ≤±1.5%h

main motors list

install capacity 9978KW
