product description
Technical Parameters

maker: china brand

material specs:

● Material type: stainless steel, carbon steel

● thickness：2.0～4.0mm

● width：900～1250mm

● coil weight：max 25tons

● coil OD：φ2000mm（max）

● coil OD：φ760mm

finished product:

● thickness：0.25～0.5mm

● width：900～1250mm

● coil weight：max 25tons

● coil OD：φ2000mm（max）

● coil OD：φ610mm

craft process:

loading car and saddle—uncoiler-straightening machine-assist coiling machine-right coiler-unloading car and saddle-before rolling devices-rolling mill-after rolling devices-left coiler-unloading car and saddle-assist coiling machine

scope of supply

no.	name	qty	remark
	mechanical devices
1	loading car and saddle	1set
2	uncoiler	1set
3	straightening machine	1set
4	right coiler	1set
5	before rolling devices	1set
6	rolling mill（without fume exhaust fan and pipes）	1set
7	main transmission device	1set
8	after rolling devices	1set
9	left coiler	1set
10	unloading car and saddle	2sets
11	interleaver（with steel table）	6sets
12	rolls changing device	1set
13	assist coiling machine	2sets
14	rolls box reverse device	1set
	hydraulic and lubrication devices
1	AGC system hydraulic station	1set
2	rolls curve hydraulic system	1set
3	normal transmission hydraulic system	1set
4	craft lubrication system	1set	provided by buyer
5	oil lubrication system（630L/min）	1set
	DC motors（main motor、coiling motor）	6units
	electrical control system（with AGC electrical control）	1set	provided by buyer
	thickness gauges	2sets	provided by buyer

approximate installation capacity: 5650kw

with one year warranty
