2002-2003 OD219-508×16mm ERW tubemill API
stock No.: 479, it is written on February 14, 2023- product description
- Technical Parameters
machine was made in 2002-2003, Chinese brand. on line.
last running date: 2016 (estimate)
tube OD: 219-508mm, max Wall thickness: 16mm Q 234. API applications.
scope of supply:
uncoiler (one side 75kw AC motor), 2+5 leveler (15kw AC motor), shear, welding plate form,
feeding machine before accumulator, 55/75 kw DC motor
hoop cage accumulator,
feeding machine after accumulator, 55kw/75kw
edge miller,
feeding machine before BD cage forming machine, DC 55 kw
cage forming machine (no power), 12 vertyical stands
Fin pass 3 stand, 55.75 DC motor
1200kw vacuum tube HF welder
2 stand scarf for OD welding beam
2 roll feeding machine, 75kw DC
3 sets of MF welding seam annealer 600kw x3
40-50m length air cooling conveyor
3 stands sizing machine, 132kw DC x3
1 Turk head stand ( 4rolls)
Cutting machine,
run out table
one set of rolls: 232mm OD
12-14m length Hydro tester, one set (2 stations)
12m end facing machine, 2 sets, 4 stations
