Cegedur Pechiney 1550mm roll caster

Stock No.: 400, it is written on August 30, 2022
  • product description
  • Technical Parameters

Cegedur Pechiney 1550mm roll caster

Material: 1000, 3000, 5000 and 8000 series

Coil thickness: 6-12mm

Coil width: 800-1550mm

Coil ID: 508-610mm

Coil OD: max. 1800mm

Coil weight: max. 10 ton

Line speed: 0.8-1.1 m/min

Recoiler tension: 130KN

Main motor power: 24.3KW

Recoiler motor power: 5.9KW

Roll size: Ф(560-620)mm×1750mm

Direction: right to left

Manufacturer:Cegedur Pechiney

Electric system manufacturer: Tianzhong
