Production scale, raw materials and product specifications

1.1 production varieties

Ordinary carbon steel, low alloy steel

1.2 blank specification bill szie:

Blank thickness: 150-200mm

Maximum width of blank: 350-500mm

Blank length: 6000-8000mm

Maximum weight of blank: 8 T

1.3 product specification:

Product thickness: 1.8 - 6mm

Coil width: 350-500mm

1.4 production scale:

The annual output of various specifications of hot rolled steel coils is 500000 tons

1.5 the whole production is about 265m long and can be built in a 24m (width) workshop

Scope of supply:

coneying roller table 1 set

working roller table  1 set

phosphorus removal by high pressure water 1 set

750 reversible rolling mill train  1 set  including motor, gear base

reversible vertical mill  1 set  including motor and reducer

hot shear  1 set

700 4 hi mill train  10 sets including motor and reducer

vertical mill 1 set including motor and reducer

electric looper 6 sets

horizontal coiler 1 set

roll front roller table  1 set

hydraulic system 1 set

lubrication system  1 set

electric control system  1 set  excluding high pressure part
