used 550mm hot rolling mill steel coil

Stock No.: 203. It is written December 3, 2021

  • product description
  • Technical Parameters

machine is made in 2006, stopped running in 2019

input slab size: 6000 x300 x 150 To 6000 x 600 x 200 in mm. (length*width*thickness)

9 horizontal stand, 2 vertical stand plus 2 Hi hot rolling plus 2 high reversible billet opening 700 hot rolling mill, vertical double winding. 9 horizontal and 1 vertical in finish rolling area,


max coil width: 550mm


annul production: 700,000 tons

material: Q195, Q235

4 roll rolling, working rotation, support Φ 550 x680 work roll Φ 350 x 700

The power of main motor is 1500KW for 9-3 groups and 2000KW for 1-2 groups. The 9th group of finished frame AGC.

Work roll of hot rolling mill Φ 750x700 ,main motor power 3300KW

working roll of 2-roll blank opening unit Φ 600x700, main motor power 1500KW

The heating furnace is excluded
