2020 Chinese brand OD10-25mm bar mill

used hot rolling mill

Your current location：首页 > Products > used hot rolling mill > 2020 Chinese brand OD10-25mm bar mill

stock No.: 267, it is written on March 30, 2022

product description
Technical Parameters

No.	frame			Transmission mode	Power (kw)	Speed (R / min)	model	region
	name	Roll OD	OD×length(Roll)	Transmission mode	Power (kw)	Speed (R / min)	model	region
1	K01 rack	280-360	Φ320×600	K1 is single drive	1250	500/1000	Z710-400	finish rolling
2	K02 rack	280-360	Φ320×600	K2 is single drive	1250	500/1000	Z710-400
3	K03 rack	280-360	Φ320×600	K3 and K4 are 1 stand 2 motors			Z630-38
4	K04 rack	280-360	Φ320×600	K3 and K4 are 1 stand 2 motors	1000	500/1000
5	K05 rack	280-360	Φ320×600	K11 and K12 are 1 stand 2 motors			Z710-500
6	K06 rack	280-360	Φ320×600	K11 and K12 are 1 stand 2 motors	1250	500/1000
1	K07 rack	320-380	Φ350×700	K11 and K12 are 1 stand 2 motors			Z710-500	Medium rolling
2	K08 rack	320-380	Φ350×700	K11 and K12 are 1 stand 2 motors	1250	500/1000
3	K09 rack	320-380	Φ350×700	K11 and K12 are 1 stand 2 motors			Z710-500
4	K10 rack	320-380	Φ350×700	K11 and K12 are 1 stand 2 motors	1250	500/1000
5	K11 rack	320-380	Φ350×700	K11 and K12 are 1 stand 2 motors			Z710-500
6	K12 rack	320-380	Φ350×700	K11 and K12 are 1 stand 2 motors	1250	500/1000
7	K13 rack	320-380	Φ350×700	K13 and K14 are 1 stand 2 motors			Z710-500
8	K14 rack	320-380	Φ350×700	K13 and K14 are 1 stand 2 motors	1250	500/1000
1	K15 rack	380-430	Φ400×1000	K15 and K16 are 1 stand 2 motors			YR800-12	rough rolling
2	K16 rack	380-430	Φ400×1000	K15 and K16 are 1 stand 2 motors	630	493
3	K17 rack	420-480	Φ450×1000	K17, K19 and K18 are synchronous 1 stand 2 motors			YR800-12
4	K18 rack	420-480	Φ450×1000	K19 and K18 are synchronous 1 stand 2 motors	630	494
5	K19 rack	420-480	Φ450×1000
6	K20 rack	520-600	Φ550×1000		1250	494	YR800-12
7	K21 rack	520-600	Φ550×1000	K20 and K21 are 1 stand 2 motors

If you want to quote or further information on this product, please fill out the form below.
