Material：Hot rolled coil 201,202,304 stainless steel

Max yield limit σs≤360N/mm2

Coil thickness：2.5-3mm

Coil width：600-800mm

Coil ID：φ510mm

Coil OD：φ900-φ1800mm

Max Coil weight：12t

Product specification：

Coil thickness：0.2-0.1mm

Coil width：600-750mm

Coil ID：φ510mm

Coil OD：φ900-φ1800mm

Max coil weight：12t

Positive and negative bending force of Intermediate roll：300/400KN

Transverse displacement of Intermediate roll：100mm

General hydraulic transmission system pressure：12MPa

Pressure of roll bending system：16MPa

AGC Pressure reduction system：21MPa

Installation capacity of motor：Approximately 3000KW

Roll machine specification：φ750*900mm

Max roll pressure：11000KN

Threading speed：18m/min

Roll speed：0-300m/min

Coil tension：100-150KN

Max coil speed：300m/min

Speed accuracy of Roll mill：<1%

Roll mill tension accuracy： Dynamic  Max tension*8/100

                                               Steady state  Max tension*3/100

Remarks: doesnot include DC motor,does not include electric system.
