main specs：

2.1 material specs：

1.material and strength：cold rolling plate Q235，σs≤235MPa，σb≤450Mpa。

2.thickness：         0.6～2.5mm

3.width：         800 ～1500mm

5.coil ID：       Ø508mm/Ø610mm

6.coil OD：       Ø1200mm ～ Ø1800mm

7.coil weight：       15t

2.2 finished product spec：

1.surface quality： thickness not changed, coil surface flat；

2. coil ID：       Ø508mm

2.3 line specs：

1．line standard height：     900mm above floor

2. max running speed without load： ≤50m/min

3．line power：   ≈180kw

4．line area： ≈22.5m×8m（L×W）

2.4 environment:

1. environment temperature：     -15~40℃

2. relative humidity：     ≤90％

3. working power： AC380V±10%，50HZ ±2% three-phase four-wire system

4. compressed air pressure：        0.4-0.6Mpa

5. air flow：              ≈1m³/min

2.5 color

1）main color：        white

2）moving and security part：    yellow

3）electrical cabinet, control table and oil tanks：grey white（RAL7032）

2.paint：flareout, no sagging, orange skin and pinhole bubble, non-efflorescent 。

2.7scope of supply
