Inlet material parameters：

Material：Cold rolling mild steel,GI steel

Thickness：0.2～2.5mm

Width：300 ～1600mm

Mechanical properties：Tensile strength σb≤500MPa；Yield limit σS≤300MPa

Coil ID：Ø508-Ø610mm

Coil Max OD：Ø1800mm

Coil weight：20t

Product parameters：

Thickness：Do not change the raw material thickness

Coil ID：Ø508mm

Coil OD：≤Ø1800mm

Coil max weight：20 t

Slitting numbers：0.2~1.0mm 25；1.1~2.0mm  15；2.1~2.5mm 8

Width accuracy：0.2~1.0mm ±0.05mm；1.1~2.0mm ±0.10mm；2.1~2.5mm ±0.12mm

Straightness (sickle bending)：Width＞300mm，≤0.35mm/m

Product burr：≤thickness×2~3%mm

Min width：30mm

Edge width range：3～15mm（It should not be less than 1.5 times the thickness of the plate.）

Max edge weight：≤150kg/coil

Staggered edge accuracy：±0.5mm

Tower tolerance：±3.0mm（Inner part excluded）

Surface quality：No machining defects are added to the surface of finished products after processing.

Unit parameters：

Threading speed：15m/min

Shearing speed：0～150m/min（Stepless adjustment according to the parameters of plate thickness and strip number）

Slitting model：Servo shearing

Recoil type：Coil type

Slitting blade numbers：Reserved tool changer arm

Unit operation elevation：+1100mm

Total unit capacity：Approximately 280KW（Accurate values are based on final design）

Unit weight：Approximately 89 t

Unit area：Approximately 27000X8500mm（length X width）

Operating direction：Operators operate from left to right on the side of the unit.

Working Conditions for Equipment

Power supply conditions：3φAC ，380V±10%，50Hz±1%

Gas source：compressed air：pressure：0.5～0.6MPa   displacement： 1m3/min

Water source：No requirement

Environmental conditions infactory buildings： tempurature   -5℃ ～40℃

Relative humidity≤90%（non-condensing）
