rolling mill size： E450/E1050X1450mm

max finished coill thickness： 6.00mm

min finished coill thickness： 0.4mm（rolling），when leveling：0.15mm；

max finished coill width： 1300mm

min finished coill width：  800mm

max coil OD：     2200mm

material coil ID：Φ508-610mm, finished coill ID：Φ610mm

max coil weight：           25T

max rolling force： 18000KN

max rolling torque： 121.5KN&m

max rolling speed： 600m/min

working roll diameter：   E450mm      new rolls

                              E410mm      old rolls

back up roll diameter：  E1050mm     new rolls

                              E980mm      old rolls

tension roll diameter：   E610mm

anti-wrinkle roll diameter：   E255mm

roll length：       1450mm     （working roll）

                 1400mm     （back up roll）

                 1450mm     （tension roll ）

                 1450mm     （anti-wrinkle roll）

max open mouth：    40mm      （when max roll diameter）

coiler cone diameter：   E610mm/E595mm jaw

coiler max tension：    300kN

max tension at exit when leveling：      180KN

transmission：          driven by working rolls

max coiling speed：      600m/min

uncoiler cone diameter:(expanding):  E610mm-E560mm（E508mm-E460mm）

uncoiler cone shaft direction fluctuation：    ±75 mm

uncoiler max tension：          100kN

max tension at entrance when leveling：      144KN

house：whole body forge，section area: 580X500mm2

rolling line standard height：        +1000 mm

rolling line standard height adjusting travel distance： 75mm

craft lubircaton flow：       5000l/min

hydraulic system working pressure：

balance、roll bending：system working pressure：

system working pressure：  21MPa   system flow：       40 L/min

CPC uncoiler auto center hydraulic control system：

  system working pressure：    16MPa       system flow：        40 L/min

common hydraulic transmission system pressure:

system flow: Q=120 L/min ；        system working pressure: 12MPa ；

AGC press system pressure:

design max pressure 32Mpa，working pressure  25Mpa，system flow 187L/min

GC servo hydraulic cylinder：when single cylinder force 9000KN，oil pressure 18.5Mpa

rolls balance：hydraulic multi-cylinder balance

main motors power:

rolling mill main motor：  DC 1500KW，  750V， 350/1000r/min， 2 units

right tension roll motor：DC 280KW，   400V,  1000/1600r/min, 2 units

left tension roll motor：DC 355KW，   400V,  1000/1600r/min, 2 units

uncoiler motor：    DC 540KW，   660V， 350/1000r/min， 1 unit

left and right coilers motors：DC 1700KW，  780V， 300/1000r/min,  4 units

      roll changing device：hydraulic changing for back up rolls，car changing for working rolls
