The used 1250mm Tension Leveler is made in 2012 and shutdown in 2017.The equipment weight is approximately 210 tons.The written date is March 29,2019.

product description
Technical Parameters

Main unit parameters

Yield

Input：300000t

Output：300000t

Material specification

Material: Cold rolled carbon steel

Yield strength：Max. 350N/mm2

Thickness：0.2～1.5mm

Width：900～1250mm

Coil OD：Φ900～Φ1900mm

Coil ID：Φ508mm/Φ610mm

Coil weight：Max. 25t

Material state

The inlet coil must satisfy the following conditions：

（a）Accident，Flatness

H/P≤2％（On the strip edge）

H/P≤1.5％（In strip center）

Whether at the edge or the center of the strip, the wave height of the strip is less than 10 mm per 1000 mm.

（b）Edge wave

The strip must be free of unilateral waves along the whole length direction.

（c）Sickle bending of Strip

Strip sickle bending should not exceed 10 mm in any 1000mm length.

（d）The thickness deviation of strip is less than ±5％.

（e）Strip crack

Edge part：Strip thickness £ 0.4mm :Max length. 3mm：

Strip thickness > 0.4mm: Max length. 5mm

Middle：Max length. 10mm

（f）Width deviation of strip：0～＋6mm

（g）Turriform:less than 30mm

（h）Surface defects of Strip

Strip surface must be free from any serious defects. Severe surface defects are layered, severely super-thick, scar and laminated strip steel.

Products

Strip thickness：0.2～1.5mm

Strip width：900～1250mm

Coil weight：5t～10t

Coil OD：Φ900～1500mm

Coil ID： f508mm，f610mm（Diameter increasing plate）

Unit speed

Process speed：Max.200m/min

Threading speed：30 m/min

Normal acceleration/deceleration:15m/min/s

Fast parking deceleration: 30m/min/s

Accidental shutdown: 7s

The scope of supply is including :

NO.	Name	Qty.
NO.	Name	Qty.
1	Inlet coil saddle	2
2	Inlet coil car	1
3	Roll pressing device	1
4	Uncoiler	1
5	Uncoiler outer support	1
6	Steering pinch roll and Guiding plate assembly	1
7	Cutting shears	1
8	Cutting head collecting device	1
9	Transition guide plate platform	1
10	Welder	1
11	Pinching deviation correction roll（with CPC）	1
12	Circle shear	1
13	Scrap edge coiler	1
14	Deburring machine	1
15	NO.1 Tension roll	1
16	Bending Leveler	1
17	NO.2 Tension roll	1
18	Examining mirror	1
19	Electrostatic oiler	1
20	Outside steering pinch roll and strip piercing table	1
21	Recoiler	1
22	EPC detection bracket	1
23	Outlet cantilever support	1
24	Wrapper	1
25	Outlet coil car	1
26	Outlet Steel Platform	1
27	Outlet coil saddle	2
28	Load cell	1
29	Welder seam detector	1
30	Elongation measurement of Tension leveler	1
31	Hydraulic station	1
32	CPC device	1
33	EPC device	1
