1650mm Tension Leveler Line Parameeters

Double bending and double straightening winding motor power 75KW

4 sets of front and rear S rolls

Entrance 1 # S roll main roll 45KW auxiliary roll 22KW

2 # S roll main roll 132KW auxiliary roll 75KW

Exit 1 # S roll main roll 160KW auxiliary roll 90KW

2 # S roll main roll main roll 55KW auxiliary roll 30KW.

The width of the straightening plate is 700 mm-1500 mm and the thickness is 0.2 mm-2.5 mm respectively.

The speed of the equipment is 300 meters per minute.

The 8-hour output is 300-400 tons, including feeding and unloading time, and the width of the sheet is not uniform.
