SL No.122 Used 20*2500mm Slitter

Used 20*2500mm Slitter.The written time is October 19,2020.
  • product description
  • Technical Parameters

Material  mild steel

Thickness range 6-20mm

Coil width range 800-2500mm

Max coil weight 35tons

Coil ID 500-800mm

Coil OD 800-2200mm

Slitting speed Max 20m/min

Slitter strip number:3PCS(15-20mm)

Total power:Approximate 960KW

Scope of supply:

V-shaped pre-discharging platform

Hydraulic Coil car

Hydraulic cone discharging machine

Hydraulic pressure drawing mechanism, hydraulic moving straight head mechanism, hydraulic shovel prying mechanism

pinch leveler

Cutting shears

Transition table

Electric guiding mechanism

Slitting machine

Hydraulic expanding and shrinking edging machine (one on the left and one on the left)

Hydraulic storage bridge(effective length 12 m)

Pre separation tension mechanism

Hydraulic pressure separation and coiling mechanism

Recoiler unit

Hydraulic unloading car

Hydraulic system

Electric system
