Main Technical Parameters:

Coil Thickness range:3 -14mm

Coil Material: Applicable for stainless steel plate with tensile strength 685mpa

Coil Width range: 800-2100mm

Coil Outer Diameter (O.D.) range: Ø 1000 - Ø 2000mm

Coil Inner Diameter (I.D.) range: Ø 508 - Ø 610mmm

Max Coil Weight: 35 Tons (T)

Shearing Accuracy:

Length Tolerance: ±1.0mm/2000mm

Diagonal Tolerance: ±1.5mm/2000mm

Flatness Tolerance: Better than GB709-88 National Standard (1/2 of the value specified by the national standard)

Levelling Speed: 0-30 m/min

Edge Trimming Accuracy: ±0.15mm

Edge Trimming Plate Thickness: 14mm (Max thickness capable of being trimmed)

electric motor parameters:

1.rough levelling electric motor: 55kw DC

2.trimmer electric motor：30kw DC

3.precise levelling electric motor：160kw DC

4. shear electric motor：30kw DC.

 scope of supply

V-type Pre-loading Table, Hydraulic Loading Car, Hydraulic Expansion Uncoiler,

Paper Collection Mechanism, Hydraulic Pinch Roll Feeding, Peeling/End Lifter, Straightening,

Pinching and Initial Levelling Mechanism, Transition Table,

Double-Roller Guide Hydraulic Press Plate Mechanism, Cantilever Edge Trimming Unit, Roller Table,

Scrap Edge Handling Mechanism, Guide Centering Mechanism, Levelling Unit, Encoding & Length Determination, Tail End Pinch Conveying Mechanism,

 Film Lamination Mechanism, Cross-Cutting Machine, Swing-type Pneumatic Pinch Conveyor, Pneumatic Blanking/Dropping Rack, "X" Lifting Table,

Discharge Car, Hydraulic System,Pneumatic System, Electrical Control System.
