Coil width 800-2200mm

Coil ID Φ508 - Φ762

Coil OD Φ1200 - 2200mm

Max coil weight: 40Ton

Max strength:  X60(σb ≤758MPa) X80(σb ≤827MPa)

2 Production method:

Steel plate with a thickness below 12mm, tension slitter;

Steel plate with a thickness above 12mm, active slitter.

3  Slitting Speed: 20-50m/min

4 Capacity of production:

Coil thickness between 3.2-8mm, Number of slitter strips: 5, Slitting speed (Material X80): 30-50m/min.

Coil thickness between 8 - 12.7mm, Number of shear strips: 4, slitting speed (Material X80): 25-45m/min.

Coil thickness between 12.7 - 16mm, Number of shear strips: 4, slitting speed (Material X80): 20-35m/min.

5 Product specifications:

Coil width: 400-2150±0.5-1mm

Width tolerance: ≤±0.5mm

Camber (max): 15mm/5m

Trim waste width: 5-25mm

Coil inner diameter: Φ760mm ±10mm

Slitting burr: ≤1mm

Maximum coil telescoping: 30mm

Production flow direction: Right to left on operator side
