used 2011 Huaxincheng spiral welding machine 2540mm

No:690 Written date:June 30,2026

product description
Technical Parameters

Scope of supply: coil car, uncoiler, leveler, shear, edge miller, feeding machine, forming machine, ROT, Lincoln welder (6), 1500A (3), 1200A(3), plasma cutter.

Spiral pipe OD: 508-2540mm, coil width 1000--2000mm , thickness: 8-25mm, Q235.

X70, max thickness: 16mm， tube length max 20m

Leveler motor : 45kw

Edge miller: 2x45kw, blade diameter: 600mm

Feeding machine motor: 2x45kw, roll diameter: 550mm
