used 610-2540mm spiral welding tubemill

input coil width:1850mm

diameter:610mm-2540mm

machine is made in 2011

coil thickness: max. Q235 25mm

coil OD: 2000mm

coil ID: 760mm

max. coil weight: 30 ton

material: Q235, X70, can make API pipe

pipe length:5000-12000mm

double cone uncoiler power: 15kw x2sets

leveler power: 110kw x 1set

delivery machine power: 55kw X 2sets

edge miller power: 75kw x 4sets

end facing machine: 2540x25mm(pipe diameter 610-2540mm)

thickness 8-25mm

pipe length:5000-12000mm

diameter expander(14200X22),pipe length12500mm

hydrotester: 2800 ton, 2540mm(pipe diameter610-2540mm)

pipe length:5000-12000mm

1.list of equipments

1.coil car   (electric motor 15kw)

2.uncoiler

3.coil opener

4.2 roll leveler

5. vertical roll

6. shear welding table

7.leveler

8. edge miller

9.guiding device

10.delivery machine

11.froming machine

12.gantry frame

13.tube cutter

14.runout table

15.fly welding part base

16. rear part base

17.  electric system, hydraulic system

18 .OD and ID welding device     (including Lincoln welder x4)
