Seamless Tube Mill
Used 273 Seamless Tubemill in Shanghai, China
Product No. 654 written on Feb 2, 2026- product description
- Technical Parameters
1. Billet Diameter: 160mm - 280mm | Length: 2000mm - 4000mm
2. Shell Diameter: 170mm - 330mm | Shell Wall Thickness: 7mm - 20mm
3. Hollow Shell Diameter: 170mm - 335mm | Hollow Shell Wall Thickness: 5.5mm - 18mm
4. Hollow Shell Length: 11000mm
5. Finished Pipe Diameter: 159mm - 280mm | Wall Thickness: 6mm - 18mm | Finished Pipe Length: 13000m
6. Main Motor Model: YRKK800-8 | Power (kW): 2250 | Voltage (V): Stator 10000V
7. Main Reducer Model: ZD80 | Gear Ratio (i): 8
8. Universal Drive Shaft Model: SWC500*4130mm (telescopic stroke 300mm)
9. Mill Roll Diameter (mm): 950
10. Mill Roll Length (mm): 910
11. Mill Roll Inclination Angle (°): 8
12. Mill Roll Speed (rpm): 93
13. Roll Material: 50Mn (Manganese Steel Grade)
14. Number of Centering Roll Units: 6 stands
15. Piercing Bar Car Speed (m/s): 82 m/s
If you want to quote or further information on this product, please fill out the form below.
