Material Parameters:

- Material Type: Cold-rolled hard steel coil

- Thickness: 0.2–1.2 mm

- Width: 800–1250 mm

- Coil Weight: Max. 25 tons

- Coil Outer Diameter: Max. 2100 mm

- Coil Inner Diameter: 508 mm, 610 mm

- Oil Content: < 1800 mg/m²

- Mechanical Properties: Yield strength 710 N/mm²

Product Parameters:

- Thickness: 0.2–1.2 mm

- Width: 800–1250 mm

- Coil Weight: Max. 10,000 kg

- Coil Outer Diameter: Max. 1500 mm

- Coil Inner Diameter: 508 mm / 610 mm

- Coating Weight: 60–180 g/m² (double-side, equal thickness)

- Surface Condition: Regular spangle or zero spangle

running speed: 100m per min
